Advantech CIRCUIT BOARD, WISE-4012E IoT Developer Kit with WebAccess (WISE-4012E-AE-WA)
Deskripsi
| Category | Attribute | Value |
| Analog Input | Channels | 2 |
| Analog Input | Input Range | 0~10 V |
| Analog Input | Resolution(Bits) | 12-bit |
| Analog Input | Sampling Rates(S/s) | 10 Hz (sum) |
| General | Connectors | 1 x Plug-in screw terminal, 1 x Micro USB |
| General | Protocol | Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, MQTT |
| Hardware | Certification | CE, FCC Class A, R&TTE, NCC, SRRC, RoHS, ANATEL |
| Hardware | LED Indicators | Status/Com, AP/Infra, Signal Strength |
| Hardware | Power Consumption | 1.5 W @ 5 VDC |
| Hardware | Power Input | 5 VDC |
| Hardware | Watchdog Timer | 1.6 s |
| Digital Input | Channels | 2 (TTL) |
| Digital Input | Input Voltage | Dry Contact Logic level 0: open Logic level 1: close to Iso.GND |
| Environment | Operating Temperature | -25~70 °C (-13~158 °F) |
| Environment | Relative Humidity | 20~95% RH (non-condensing) |
| Environment | Storage Humidity | 0~95% RH (non-condensing) |
| Environment | Storage Temperature | -40~85 °C (-40~185 °F) |
| Relay Output | Channels | 2 Form A |
| Relay Output | Contact Rating (Resistive) | 1 A @ 30 VDC |
| Relay Output | Relay Type | 2 x Form A |
| Relay Output | Resistance | Min. 1 GΩ min. |
| Power Requirements | Input Voltage | 5 VDC |
| Mechanical | Dimension (W x H x D) | 80 x 139 x 25 mm |
| Mechanical | Enclosure | PC |
| Mechanical | Weight (Net) | 0.16 kg |
| Wireless Communication | Frequency Band | IEEE 802.11 b/g/n 2.4 (GHz) |
| Wireless Communication | Standard(Technology) | WIFI |
