H3C 55V 60W PoE Adapter Power Supply
Rp1.907.645
Deskripsi
spesifikasi H3C 55V 60W PoE
| Size（W×D×H） | 208.5mm × 85mm × 46mm |
| Weight | 437g |
| Input Voltage | 100V AC～240V AC；50/60Hz |
| Input Current | 1.5A Max, at 115Vac, Full load
0.75A Max, at 230Vac, Full load |
| Input Connector* | IEC320 C14 |
| AC Inrush Current | 30A Max. At 115Vac, Cold start.
60A Max. At 230Vac, Cold start |
| Output Voltage | 55V |
| Output rated current | 1.1A |
| Total Output Power | 60W |
| Output Connection | Pins 3,6, 4,5(+) Pins 1,2, 7,8 (-) |
| Power Efficiency | Level V |
| Protection | OCP,OVP,SCP |
| Temperature | Operation: -30℃～55℃
Non-operation: -40℃～70℃ |
| Humidity（Non-condensing） | 5%～95% |
| Altitude | Up to 5000m |
| EMC | EN 55032: RE,CE
CISPR 32: RE,CE IEC 61000-4-2: ESD IEC 61000-4-3: RS IEC 61000-4-4: EFT IEC 61000-4-5: Surge IEC 61000-4-6: CS IEC 61000-4-11: DIPS |
| Safety Approvals | CE,TUV, CCC |
