Name: Huawei Enterprise Router AR2240-S
SKU: AR2240-S
Availability: InStock

Huawei Enterprise Router AR2240-S

Rp50.815.800

Item	Specification
System parameters	Depending on the SRU that is used
Dimensions and weight
Dimensions (H x W x D)	With no mounting bracket installed: 88.1 mm x 442.0 mm x 470.0 mm (3.47 in. x 17.40 in. x 18.50 in.) With mounting brackets installed: 88.1 mm x 482.6 mm x 470.0 mm (3.47 in. x 19.00 in. x 18.50 in.)
Weight	8.85 kg (19.51 lb)
Power specifications	AC input voltage Rated input voltage range: 100 V to 240 V, 50 Hz/60 Hz Maximum input voltage range: 90 V to 264 V, 47 Hz to 63 Hz
Heat dissipation
Fans	Independent pluggable fan modules
Airflow (facing the front panel)	Left to right
Interface density	Depending on the SRU that is used
Interface density
Extended slots	4xSIC 2xWSIC 2xXSIC
DSP DIMM slot	Supported
Environment parameters
Operating temperature	0°C to 45°C (32°F to 113°F) NOTE: When the altitude is 1800 m-5000 m (5906ft.-16404.2 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Storage temperature	-40°C to +70°C (-40°F to +158°F)
Operating relative humidity	5% to 95%, noncondensing
Operating altitude	< 5000 m (16404.2 ft.)
Part number	02113993
